Eurorack module

Peak+Hold MinijackPeak+Hold Banana

Peak+Hold

Dynamic Percussion Interface

  • Dynamic signal processing
  • 9 different CV/signal outputs
  • Manual level, trigger and filter controls of the input signal
  • Selectable frequency band (for cascading 2 or more P+Hs)
  • Pickup included
  • Optional with banana or 3,5mm minijack sockets



more…

new

  • Width: 10 HP
  • Dimensions: 128,5 mm x 50,5 mm
  • Depth: 35mm
  • Supply voltage: ±12V
  • Consumption: max. 65mA

Eurorack module

XR22 VCO FT Minijack VersionXR22 VCO FT Banana Version

XR22 VCO FT

VCO with Amplitude Modulation and FSK (Frequency Shift Keying)

The XR22 VCO FT  is a modified version of the previous model XR22 VCO with a different manual frequency control.



  • AM (Amplitude Modulation) Input
    • Ring modulation
    • CV controllable sine/triangle volume
    • Advanced waveform generation with feedback
  • FSK (Frequency Shift Keying)
    • Pulse and ramp generation
    • Switching between two different frequency CVs
    • Advanced waveform generating
  • LFO-, Bass-, High- Mode
  • Optional with Banana or 3,5mm Phone Sockets

more…

  • Width: 12 HP
  • Dimensions:128,5 mm x 60,6 mm
  • Depth: 35mm
  • Current consumption:≈70mA

Eurorack module

X Minijack VersionX Banana Version

X

4-Quadrant Multiplier



  • Working both with audio and CV signals
  • Ring / amplitude modulation
  • Voltage controlled amplification
  • Exponential conversion
  • Wave shaping
  • Dynamic expansion
  • One input with adjustable offset voltage
  • Easy to use
  • Optional with banana or 3,5mm minijack


more…

  • Width: 6 HP

  • Dimensions: 128,5 mm x 30,2 mm
  • Depth: 35mm
  • Supply voltage: ±12V
  • Current consumption: ≈25mA


Eurorack module

Delay1022 minijack versionDelay1022 banana version

Delay1022

Analogue BBD delay

This module is no classic echo, but a delay designed for audio rate feedback and sound sculpturing.

  • Delay times from 2.5 ms to 50ms (without T CVin)
  • CV controllable delay time (≙ feedback frequency)
  • Feedback CV control input
  • 2nd delay output behind feedback-contolling VCA
  • Manually controllable output lowpass (12dB)
  • Available with banana or 3,5mm minijacks



more…

  • Width: 12 HP
  • Dimensions:
    128,5 mm x 60,6mm
  • Depth: 52mm
  • Supply voltage: ±12V
  • Power consumption: ≈ 90mA

Eurorack module

PCV1PCV3

Patch Converter

Format conversion between
banana ↔ minijack
or
banana ↔ minijack ↔ 6,3mm jack
